Impact Driver Basics
To better understand how an impact driver works, let’s compare and contrast it with your standard drills and hammer drills.
A standard drill is a handheld power tool that is used to bore holes or drive screws into wood and some metals. Its motor produces a simple rotary motion to bore a hole or drive a fastener into the material. You can use it to drill holes through concrete or masonry, but it should be done carefully or it’s going to shorten the life of your drill.
Hammer drills, on the other hand, are perfect for brick, concrete, and stone. Unlike standard drills, hammer drills don’t just produce a regular rotary motion. These power tools combine rotary drilling with a very fast hammering motion to bore through masonry.
Despite their sheer power and ability to create a hole through the toughest materials, driving screws is not something hammer drills can do. This is a job for another type of power tool called the impact driver.
Impact drivers are high-torque power tools used to drive larger self-threading screws into dense materials. Unlike standard and hammer drills, their chucks only use ¼” hex-shank driver bits and drills. They can also be used to loosen and extract screws, nuts, and bolts. If you have corroded or over-torqued fasteners and you’ve tried every trick in the book to remove them but to no avail, then having an impact driver can definitely help you.
These tools are almost similar to hammer drill in which they combine rotary motion and hammering action. Hammer drills, however, use a simple tapping motion to bore through masonry. Impact drivers, on the other hand, use hammering blows that do not just go downwards, but also move side to side, to drive larger screws into the material. Take a look at this video to learn more about how an impact driver works.
Impact Driver Buyer’s Guide
Torque
When you pick up an impact driver’s box or manual, you’ll notice the ubiquity of information about its torque rating. That’s because torque is one of the most important factors to consider when choosing the best impact drivers.
Torque (or max torque) is the amount of rotational force (not the speed) generated by a power tool. It is rated in inch-pounds (in-lbs) or Newton-meter (N⋅m if you’re using SI units). Because they generate an enormous amount of torque, impact drivers are perfect for driving longer screws into dense materials.
When choosing the best impact driver, look for one that generates a lot of torque. Couple that with a high-voltage battery, and you have the perfect tool. If you’re going to use it for drilling, then make sure that it produces high RPM, too.
Excessive torque is a common problem for single-speed impact drivers. It can result in thread damage and stripped or snapped heads, especially if you’re using smaller and delicate fasteners. To prevent excessive torque, choose an impact driver with a variable speed setting. This allows you greater control of the tool by starting slowly, then increasing the speed as you go along.
Brushless Versus Brush Motor
Impact drivers with brush motors are reliable and inexpensive. The problem with impact drivers with brush motors is that their carbon brushes eventually wear out and need to be replaced. Impact drivers with brush motors, however, are very rare these days and have largely been replaced by brushless motors.
Power tools with brushless motors are more reliable when it comes to performance and power. They are more expensive, but you can save money in the long term as you don’t have to replace the carbon brushes now and then.
Battery Voltage
Some impact drivers are powered by 12-volt batteries, while some are powered by 18-volt or 20-volt ones. So, which battery is perfect for your application?
12V impact drivers are ideal light-duty applications. If you’re driving smaller or moderately sized screws or you’re not going to use the tool regularly, then a 12V impact driver will suffice.
But if you’re planning to drive a lot of screws in one day or you frequently drive 3″ screws and above into dense materials, then choose the more powerful 18V or 20V impact drivers.
Is a 20V battery better than its 18V counterpart? The truth is no, both batteries work basically the same. 20V batteries might sound a little more impressive, but this is all a marketing gimmick. When you squeeze the impact driver’s trigger, the power output will surge to 20V at first and will dial down to 18V after several moments.
Amps
The maximum output of your impact driver’s battery is measured in voltage. Amp-hours (Ah), on the other hand, will tell you how long a single charge will last. Amp-hours range from as low as 1.3Ah to as high as 6Ah. If you want to get more out of your battery, then choose one with higher Amp-hours. In most cases, a 2 to 3Ah battery will suffice.
Weight
Consider the tool’s weight before buying one. If you’re going to drive more than a hundred fasteners in one day, chances are an extremely heavy tool that will take its toll on your hand, wrist, and arm. Include the battery’s overall weight into the equation, too.
LED Light
The majority of impact drivers today have a built-in LED light. This feature is important because you sometimes have to do your work in a poorly lit area of your workshop. Users with poor eyesight will also find it helpful.
Belt Hook
When choosing an impact driver, look for ones that have a metal belt hook so you can keep your tool within reach always. If you don’t want the belt hook, you can always unscrew and remove it anyway.
